Advanced Pigment Dyeing System - Apparel Impact Institute

Solution maturity level

Pre-seed

Definition:

Solutions that are at a concept level and in the process of evaluating and establishing their impact potential.

Pilot

Definition:

Solutions that are in the process of testing their solution in order to demonstrate a proof of concept.

Model

Definition:

Solutions that are working towards de-risking and reducing known barriers to scale.

Scale

Definition:

Solutions that are commercially viable with a proven go-to-market strategy.

Goal:

The objective is to achieve a substitution of 5% of reactive or vat dyeing systems.

Scale

Current Level

Pre-seed

Pilot

Model

Scale DEFINITION

Solutions that are commercially viable with a proven go-to-market strategy.

LEARN MORE ABOUT OUR MATURITY LEVELS

Current Level

Goal Of This Scale Solution

The objective is to achieve a substitution of 5% of reactive or vat dyeing systems.

Pre-seed DEFINITION

Solutions that are at a concept level and in the process of evaluating and establishing their impact potential.

LEARN MORE ABOUT OUR MATURITY LEVELS

Pilot DEFINITION

Solutions that are in the process of testing their solution in order to demonstrate a proof of concept.

LEARN MORE ABOUT OUR MATURITY LEVELS

Model DEFINITION

Solutions that are working towards de-risking and reducing known barriers to scale.

LEARN MORE ABOUT OUR MATURITY LEVELS

Location Availability

PIGMENTURA by CHT is available globally, with the exception of Canada, Australia, and South Korea.

Available regions

Sites

Portugal

9 associated sites

Spain

2 associated sites

Germany

4 associated sites

India

6 associated sites

Pakistan

1 associated sites

Poland

1 associated sites

Czech Republic

1 associated sites

United Kingdom

1 associated sites

Financial breakdown

There are no additional costs for standard equipped dyeing or finishing mills. Only the chemicals and dyes are replaced. Chemicals to be used may increase recipe cost. However, it will be compensated by savings associated to water and energy consumption reduction. Costs may vary based on factors such as country of production, color depth, and fabric composition.

Payback period

Average payback in months

Implementation Plan

PIGMENTURA by CHT is a pigment dyeing system for continuous dyeing. It consists of various auxiliaries and color pigments. CHT can provide customers with color adjustment and technical advice. On-site support for initial trials by service technicians is also available.

2 months

Projected project length

Implementation milestones

The system is first described in detail. Preliminary tests are then carried out on the customer's fabrics in the customer's or CHT laboratories. The recipes are adapted to the existing machinery. The best process parameters are developed on site in collaboration with the customer.

System explanation

Lab tests, color approval

Pilot trial

Bulk production

Case Study

1 Region

1 Site

1 Month

Impact

GHG saved

3,194

tCO2e

Energy saved

41,207

Water saved

16,463

The Challenge

A Spanish textile company partnered with CHT to evaluate the sustainability of CHT's pigment-based continuous dyeing process (Pigmentura) compared to the standard method. The study assessed water and energy consumption, CO2 emissions and production efficiency across four trials involving 100% cotton and 50% cotton/ 50% polyester blends. The analysis of Pigmentura indicates significant reductions in all evaluated variables to the standard approach. We have extrapolated the batch testing to a monthly production figure to demonstrate the scale of impact.

Solution program growth

Since 2023, Pigmentura has been deployed in 20 sites.

20

Total sites

2023–2024

3

Brands Adopting This Solution

2023–2024

Solution providers

CHT Group

The CHT Group is a global player for specialty chemicals and active in 26 countries in development, production and sales. CHT Germany GmbH is the headquarters which focuses on sustainable chemical products and process solutions. Textile Solutions of CHT improve the quality, functionality as well as look and purity of textiles and optimize their manufacturing processes.

Visit company website
